Joule Cyclone Plus Indirect Standard 90–300L Unvented Hot Water Cylinder
Joule Cyclone Plus Indirect Standard 90–300L Unvented Hot Water Cylinder
The Joule Cyclone Plus Indirect Standard cylinder range (90L, 120L, 150L, 180L, 210L, 250L, 300L) offers premium, mains-pressure hot water storage for homes and small businesses with a heat source such as a gas or oil boiler. With industry-leading Duplex stainless steel construction, high recovery smooth-tube coil, and robust insulation, these cylinders set the standard for efficiency, durability, and installer convenience.
Key Features:
- Indirect cylinder design for use with a boiler, renewable system, or compatible heat source
- Factory-fitted 3kW immersion heater for electric backup during boiler outages or off-peak use
- Capacities from 90L up to 300L to suit all property sizes
- Main pressure performance – powerful hot water supply for multiple outlets simultaneously
- High grade Duplex stainless steel construction for superior corrosion resistance
- High-performance smooth tube coil – exceptional heat transfer and rapid recovery
- 100% CFC/HCFC-free dense polyurethane foam insulation (ODP 0, GWP 1) for low standing losses and best-in-class efficiency
- Comprehensive fixing and safety kit, including Caleffi safety group, expansion vessel, T&P valve, and plastic tundish
- Modern white “white goods” outer case for a premium, easy-clean appearance
- 25-year manufacturer warranty (2 years on controls/components)
Technical Specifications (examples):
- Capacities: 90L, 120L, 150L, 180L, 210L, 250L, 300L
- Diameter: approx. 540–550mm; Height (varies): e.g., 120L – 900mm; 210L – 1494mm; 250L – 1815mm; 300L – 1600mm
- Unit Weight (empty/full): 120L ~27/147kg; 210L ~45/248kg; 250L ~57.6/307.6kg; 300L ~64/364kg
- Immersion heater: factory-fitted, 3kW @ 230V
- Standing losses: ~92W for 300L
- Maximum working pressure: 3.5 bar (with supplied kit)
- Tested to BS EN 12897:2006
- Comprehensive fitting/controls pack included
Other Details:
- Smooth tube technology minimises scale and improves efficiency in hard water
- Supplied with all fixings, expansion vessel, and safety controls
- Simple front access for all plumbing and safety connections
- Designed and built in the UK for the UK market
Why Choose Joule Cyclone Plus Indirect Standard?
For unbeatable reliability, rapid hot water recovery, and maximum durability, the Joule Cyclone Plus Indirect range delivers premium performance in every installation. With generous warranty cover, highly efficient coil, and robust stainless steel build, it’s the professional’s cylinder of choice for new builds, upgrades, or replacement projects.
