AIK-A-MAH54-445-TM | Ultra-lightweight 445W N-Type ABC module with 22.3% efficiency and black frame, ideal for premium residential and commercial rooftops.

Key Features

• 445W rated power with 22.3% module efficiency for high energy yield.
• N-Type ABC (All Back Contact) cells with no front busbars for maximum light capture and sleek aesthetics.
• Lightweight construction at only 8.6 kg, reducing roof load and easing handling.
• 54-cell, black-frame design for a clean, modern look on visible roof areas.
• Excellent temperature coefficient of -0.26%/°C for strong performance in hot conditions.
• Cell-level shade optimisation for improved output under partial shading and low light.
• Long-life design with 15-year product warranty and 30-year performance warranty.

Electrical Characteristics (STC)

Nominal Power Pmax	445 W
Module Efficiency	22.3%
Voltage at Pmax (Vmpp)	34.44 V
Current at Pmax (Impp)	12.93 A
Open Circuit Voltage (Voc)	40.88 V
Short Circuit Current (Isc)	14.02 A
Max System Voltage	1500 V DC
Pmax Temp. Coefficient	-0.26%/°C

Mechanical Specifications

Dimensions (L×W×T)	1762 × 1134 × 30 mm
Weight	8.6 kg
Cell Type / Count	N-Type ABC monocrystalline, 54-cell format
Frame	Black anodised aluminium
Connector	Staubli MC4-Evo2
Cable Length	Approx. 1.2 m
Clamp Zones	Long and short side mounting

Reliability & Warranty

• Product warranty: 15 years (AIKO residential 54 black modules range).
• Performance warranty: 30 years with extended power output guarantee (low annual degradation).
• MCS certified (e.g. reference R 50638450 0001/076) for UK installations.
• Tested for PID, salt mist, ammonia, dust and sand for long-term durability.

MPN: AIK-A-MAH54-445-TM
Model: Nebular 2P 445W N-Type ABC 54 Cell Black Frame

Award-winning lightweight N-Type ABC module combining top-tier efficiency, elegant black-frame aesthetics and advanced shade tolerance, ideal where roof load, performance and appearance all matter.
